Eighteeth Fast Fill

Description

Eighteeth Fast Fill is a cordless obturation system that heats gutta-percha in-hand and delivers it into shaped canals with fingertip control. The unit stores three programmable temperature/speed memories (100 °C – 200 °C) and reaches the set temperature quickly, while a piston-driven cartridge extrudes material smoothly at three push speeds. Disposable silver tubes in 25 Ga and 23 Ga (20 Ga optional) allow easy canal access and can be pre-bent with the supplied tool for three-dimensional fills. A lithium-ion battery powers more than one treatment cycle per charge and recharges on the green-LED docking base or via direct USB-C. Lightweight (≈1.1 kg kit) and autoclavable cartridge components simplify hygiene. Fast Fill streamlines warm vertical or back-fill techniques, improving obturation density and reducing chair time.

Key Features

• Three programmable temperature & speed memories speed up repeat cases.
• Slim disposable silver tubes (25 Ga/23 Ga) pre-bend for superior canal navigation.
• Fast 100–200 °C heater liquefies gutta-percha in seconds, reducing procedure time.
• Lithium battery delivers cordless freedom; USB-C or dock charging with clear LED.
• Autoclavable cartridge components ensure strict asepsis between patients.
• Intuitive OLED interface and audible feedback guide each workflow step.

Specifications

• Dimensions: 23 cm × 17 cm × 8 cm ± 1 cm (outer box)
• Gutta-percha size: Diameter 2.5 mm – 2.8 mm, Length 14 mm – 16 mm
• Applicable temperature: 100 °C – 200 °C
• Weight: 1.1 kg ± 10 %
• Power supply: Lithium-ion battery 3.7 V, 2600 mAh ± 10 %
• Charger power supply: AC 100 – 240 V ± 10 %
• Charger power output: 6 V 3 A
• Frequency: 50 / 60 Hz ± 10 %
• Temperature range: 100 °C – 200 °C
• Electrical safety class: Class II
• Applied part: Type B
• Operating conditions: Enclosed spaces, 5 °C – 40 °C, RH < 80 %, altitude < 3000 m, pressure 70 – 106 kPa
• Transport & storage conditions: –20 °C – +55 °C, RH 20 % – 80 %, pressure 70 – 106 kPa
• Battery: Replaceable Li-ion battery– 2600 mAh

Packaging

• 1 X Fast-Fill For Backfilling (Back Fill Device)
• 2 x Tips
• 1 x Sample GP Pellets
• 1 x Wrench
• 1 x Charger
• 1 x Charging Base

  Eighteeth Medical Fast Fill Tips: Link

Directions for Use

Preparation — Charge handpiece, load the recommended gutta-percha bar, and screw a sterile cartridge with chosen silver tube in place. Ensure program memory (T1–T3) matches desired temperature and push speed.

Heating — Short-press the main switch; the blue LED flashes while warming and stays solid when the preset temperature is reached (≈15 s).

Dispensing — Hold the push button to extrude gutta-percha; advance slowly from apex coronally, withdrawing in ≤5 s to avoid thermal injury.

Changing stick — Use the built-in “Change GP” routine to purge residue and prompt insertion of a new bar.

Post-use care — Cool to <45 °C, remove cartridge by the black shell, wipe handpiece with 70–80 % ethanol, and autoclave cartridge nuts/tubes at 134 °C / 5 min.

Additional Information

• Country of Origin: PRC
• Manufacturer: Eighteeth

Warranty & Service

• Manufacturer/Importer warranty of 1 Year against manufacturing defect
• Service and Warranty are handled by the manufacturer/importer directly for this product

• Dentalkart will not be liable to replace the Products and the liability to replace any such Product is that of the Manufacturer/Importer
• Dentalkart and the Buyer acknowledge that the Products purchased/used are a subject matter of original Manufacturer/Importer’s warranties only
• Any or all claims in relation to returns and replacement shall be made to the concerned Manufacturer/Importer only and Dentalkart may assist the customer in registering a request to get the Product replaced or serviced.
• The Buyer acknowledges that the Products once sold will not be exchanged or taken back unless the seal of the package or the Product is intact or not altered in any manner or does not tamper as the case may be.
