Woodpecker Fi-G Obturation Gun Tips 24mm – 20G (Pack of 4)

Description

Woodpecker Fi-G Obturation Gun Tips are precision-engineered accessories designed to enhance the performance of the Fi-G Endo Obturation Gun. Available in 22mm, 24mm, and 28mm lengths with gauges of 20G, 23G, and 25G, these tips are crafted to ensure precise and controlled placement of gutta-percha within the root canal. The 360° rotatable needle and 0.5mm injection diameter offer superior maneuverability and prevent leakage, facilitating efficient obturation. With rapid heating up to 230°C in just 15 seconds, these tips enable swift and effective delivery of warm obturation material. Ideal for professional endodontic procedures, they help achieve consistent, high-quality results by ensuring accurate sealing and compact filling of root canals.

• 20G – 22mm: Designed for wide canals. Allows robust delivery of heated gutta-percha.
• 20G – 24mm: Suitable for wide canals. Provides a balance of flow and reach for effective backfilling.
• 20G – 28mm: Ideal for deeper wide canals. Ensures complete obturation with a larger flow capacity.
• 23G – 24mm: Designed for medium canals. Allows for precise injection of heated gutta-percha.
• 23G – 28mm: Provides extended reach for medium canals. Effective for deeper canal obturation.
• 25G – 24mm: Suitable for narrow canals. Offers a finer diameter for controlled flow and access.

Key Features

• Multiple Lengths & Gauges: Available in 22mm, 24mm, and 28mm lengths with 20G, 23G, and 25G options
• Rapid Heating: Heats up to 230°C within 15 seconds for quick and efficient use
• 360° Rotatable Needle: Allows for precise placement and improved maneuverability during obturation
• Anti-Leakage Design: Features an anti-return structure to prevent gutta-percha leakage
• High-Quality Materials: Constructed from durable, heat-resistant materials for consistent performance
• Ergonomic Design: Lightweight and easy to handle, ensuring user comfort during procedures
• Pre-Sterilized Tips: Each tip is individually sealed, and ready for immediate use to maintain sterility

Specifications

• Lengths Available: 22mm, 24mm, 28mm
• Gauge Sizes: 20G, 23G, 25G
• Heating Temperature: Up to 230°C
• Heating Time: 15 seconds to reach maximum temperature
• Needle Diameter: 0.5mm injection needle
• Needle Rotation: 360° rotatable for enhanced maneuverability
• Pack Size: Pack of 4 tips per variant

Packaging

• 4 x Woodpecker Fi-G Obturation Gun Tips
• 1 x Protective sleeve

Directions for Use

Preparation:

• Ensure the Fi-G Obturation Gun is charged and ready for use
• Select the appropriate tip size (22mm, 24mm, or 28mm) and gauge (20G, 23G, or 25G) based on the procedure

Attachment:

• Insert the selected obturation gun tip into the Fi-G Obturation Gun
• Ensure the tip is securely fastened and properly aligned

Heating:

• Turn on the Fi-G Obturation Gun
• Wait for the tip to heat up to the desired temperature (up to 230°C), which typically takes around 15 seconds

Application:

• Position the heated tip at the entrance of the prepared root canal
• Slowly inject the gutta-percha into the canal, using the 360° rotatable needle for precise placement
• Maintain consistent pressure to ensure even distribution of the material

Finalization:

• Release the trigger to stop the flow of gutta-percha
• Allow the tip to cool down, which occurs almost instantly
• Carefully remove the tip from the obturation gun for disposal or cleaning

Aftercare:

• Clean the Fi-G Obturation Gun according to standard protocol
• Store the gun and any remaining tips in a sterile environment

Additional Information

• Country of Origin: Made in PRC
• Manufacturer: Woodpecker

Warranty & Service

• Warranty is not applicable for this product
