Frank Diamond Bur TR-23C | Made in Germany (Pack of 5)

Description

Frank Dental Tapered Round End (TR) Coarse Grain Diamond Burs (made in germany) are manufactured from the highest quality steel shanks using exquisite natural diamonds to match international specifications. This advanced manufacturing, using computer controlled precision engineering, ensures true concentricity and balance, minimising vibration and potential damage to handpiece bearings and at the same time improving cutting efficiency and product longevity.

Different grain sizes allow the targeted removal of specific volumes and maximum conservation of tooth substance. The burs are available in various sizes.

The Diamond plating of these burs is carried out under strictly controlled conditions specific to the bur pattern involved.

Key Features

• Long life diamond burs.
• Quality control tested.
• High precision.
• Reduced clogging and improved cutting efficiency.
• Unique diamond application process ensures excellent diamond particle retention and cutting surface throughout multiple uses.
• Green color-coded band on the shank – coarse grain dental burs.
• Friction grip (FG) standard shank length.
• Autoclavable.

Specifications

• Shape – Tapered Round End (TR).
• Grits available – Coarse grain
• Grit size – 107-181 microns
• Shank type – Friction grip
• Construction – Stainless steel
• Color band on shank – Green
• Autoclavable
• Compatibility: Airotors

Packaging

• 1 x Bur (Pack Of 1)
• 1 x TR-25C, TR-12C, TR-26C (Pack of 5)

Directions for Use

• Sterilization: Prior to each clinical use, sterilize the bur in an autoclave following standard dental infection control protocols to ensure aseptic handling.
• Insertion: Firmly insert the FG (Friction Grip) shank into a compatible airotors. Confirm the bur is fully seated and rotates concentrically to prevent vibration and ensure cutting accuracy.
• Clinical Application: Use the bur for efficient cavity and crown preparation, especially when rapid tooth structure reduction is required. The coarse grit provides aggressive cutting ideal for shaping inlays, onlays, crowns, and bridge preps.
• Cutting Technique: Employ steady, moderate pressure while directing the tapered round end to form rounded internal line angles, convergent axial walls for crown prep, and divergent walls for cavity, inlay, and onlay preparations.
• Cooling: Operate the bur under constant water spray to manage frictional heat, protect the pulp, and extend the lifespan of the diamond grit.
• Post-Use Handling: After completion of the procedure, rinse the bur to remove debris, disinfect thoroughly, and sterilize again before storage or next use.
• Storage: Store in a clean, dry bur block to maintain cutting integrity and prevent contamination. Regularly inspect for wear or damage and replace as needed to ensure optimal clinical performance.

Additional Information

Country of Origin: Germany

Manufacturer:
FRANK Dental GmbH
Tölzer Str. 4, 83703 Gmund am Tegernsee, Germany

Packer:
FRANK Dental GmbH
Tölzer Str. 4, 83703 Gmund am Tegernsee, Germany

Imported By:
Vasa Denticity Ltd.
Khasra No. 15/1, Mustil No. 6, Village Dabodha, Farrukhnagar, Gurugram, Haryana – 122506, India
Phone: +91 72899 99456

Warranty & Service

• Warranty is not applicable for this product.
