Xcem XC Submerged Dental Implant 5mm x 10mm (XC-5010-T)

Description

The Xcem XC Submerged Dental Implant, measuring 5mm in diameter, stands as a pinnacle of precision and innovation in dental implant technology. Specifically designed for both upper and lower alveolar bone applications, this disposable and sterile medical device serves as an artificial tooth root in dental implant surgeries. The implant showcases a 2.5 Hex fastening type with an 11-degree Morse Taper, ensuring secure and stable placement during immediate loading.

One of its notable features is the dual-thread design, operating at a remarkable speed of 1.6mm per rotation, thanks to the 0.8 Dual Thread Type. This efficiency is further enhanced by the cutting edge of the Twist Type, minimizing bone resistance while providing exceptional self-tapping ability during placement. The conical shape and lower deep thread of the fixture contribute to heightened stability upon insertion into the implant bed.

The implant’s RBM surface, achieved through blasting with a highly biocompatible Calcium-Phosphate Media, increases surface areas, thereby enhancing biocompatibility. With an overall tapered structure (Diameter – 0.7mm), this dental implant prioritizes stability and successful integration. The Xcem XC Submerged Dental Implant comes accompanied by detailed instructions, cautions, and contraindications, ensuring proper and effective usage. With its cutting-edge design and comprehensive guidelines, this implant represents a pinnacle in the realm of dental implantology.

Key Features

Precision Design:

Engineered with a 5mm diameter, ensuring precise fit and compatibility for dental implant surgeries.

Advanced Fastening System:

Utilizes a 2.5 Hex fastening type with an 11-degree Morse Taper for secure and stable placement.

Efficient Dual-Thread Design:

Incorporates a 0.8 Dual Thread Type, enabling rapid insertion at a speed of 1.6mm per rotation.

Enhanced Stability and Immediate Loading:

Conical shape and lower deep thread contribute to increased stability, facilitating immediate loading.

Biocompatible Surface Treatment:

Surface areas are increased through blasting with highly biocompatible Calcium-Phosphate Media (RBM surface).

Cutting-Edge Technology:

Features a Twist Type cutting edge that enhances self-tapping ability while minimizing bone resistance during placement.

Tapered Apex Structure:

Structured with a tapered design (Diameter – 0.7mm) for overall stability and successful integration in dental implant surgeries.

Specifications

• Fastening Type: 2.5 Hex with 11-degree Morse Taper
• Dual Thread: 0.8 Dual Thread Type (1.6mm per rotation)
• Main Thread: Conical shape, lower deep thread for stability
• RBM Surface: Biocompatible Calcium-Phosphate Media
• Cutting Edge: Twist Type for enhanced self-tapping ability
• Apex Structure: Tapered (Diameter – 0.7mm)
• Length Options: 7mm, 8.5mm, 10mm, 11.5mm, 13mm, 15mm

Packaging

• 1 x XC Submerged Dental Implant 5mm

Directions for Use

Preparation:

• Check the package for condition and expiration date.
• Ensure the product is undamaged.
• Fully understand the operation sequence and direction using surgical instruments.
• Sterilize surgical instruments for surgery (Autoclave: 121°C x 30min).

Surgical Planning:

• Collaborate with the surgery team to plan the procedure accurately.
• Ensure aseptic conditions during implantation.

Implantation:

• Open the outer box, checking the label and instructions.
• Remove packaging film.
• Open the cap of the inner ampule and carefully pull out the fixture.
• Hold the cap of the inner ampule, place the hand-piece or ratchet wrench on the inner hexa or octa of the fixture.
• Tilt the fixture to the open side, breaking the bottom neck of the fixture.

Abutment Connection:

• Apply the recommended torque (10N/cm²) when connecting the healing abutment or cover screw.
• Clean around the implant after connecting the abutment in the fixture.

Post-Surgery Care:

• Clean the oral area with saline during the healing period.
• Control bleeding by having the patient bite on gauze for one hour.
• Monitor the mucous membrane every 3-4 weeks post-insertion.
• Educate the patient on maintaining oral hygiene to prevent inflammation and infection.

Stitch Removal:

• Remove stitches after 8-9 days and check for any signs of infection.

Storage and Handling After Use:

• Use the implant only once; do not reuse.
• Store in a well-ventilated room at 12°C to 28°C, avoiding chemical storage areas.

Follow-up Visits:

• Schedule weekly visits for the first 3-4 weeks during the healing period.

Additional Information

Country of Origin: United Kingdom

Manufacturer:
XCEM Ltd.
15 Picardy Road, Belvedere, Kent, DA17 5QH, United Kingdom

Packer:
XCEM Ltd.
15 Picardy Road, Belvedere, Kent, DA17 5QH, United Kingdom

Warranty & Service

• Warranty is not applicable for this product
