Description
The Frank Dental Cylinder Flat End Diamond Bur FG SF is a high-quality dental instrument crafted in Germany, designed for precision and durability. It is ideal for cavity preparation, forming the inner walls of cavities, and placing retention grooves to ensure the stability of restorative materials. Made with fine diamond grit and durable construction, it delivers exceptional cutting efficiency and smooth operation. Suitable for fast and accurate results, it is a trusted tool for professional use in restorative dentistry.
INDICATION
- To cut cavity preparation.
- To form inner wall of cavity preparation.
- To place retention grooves in the wall of cavity preparation.
Key Features
- Delivers precise and controlled cavity shaping
- Ideal for creating flat cavity floors and parallel walls
- High-quality German engineering ensures long-term performance
- Efficient cutting reduces chairside time
- Smooth operation minimizes heat generation and patient discomfort
- Fine grit texture offers clean surface finish for better bonding
- Reliable tool for forming retention grooves in restorative procedures
Specifications
TECHNICAL SPECIFICATIONS:
| Bur Code | International Ref | Diameter | Length | Grain | Shape |
| SF-11 | D.837.012.FG | 12 | 22 mm, 22 mm | Medium | Flat cylinder |
| SF-12 | D.837.014.FG | 14 | 22 mm, 22 mm | Medium | Flat cylinder |
| SF-12C | D.837.014.G.FG | 14 | 22 mm, 22 mm | Coarse | Flat cylinder |
| SF-13 | D.837.016.FG | 16 | 22 mm, 22 mm | Medium | Flat cylinder |
| SF-21 | D.836.014.FG | 14 | 19 mm, 19 mm | Medium | Flat cylinder |
| SF-31 | D.835.012.FG | 12 | 19 mm, 19 mm | Medium | Flat cylinder |
| SF-41 | D.835.010.FG | 10 | 19 mm, 19 mm | Medium | Flat cylinder |
- Type: Diamond Bur
- Material:Stainless steel
- Category: Cavity Preparation Instrument
- Head Shape: Cylinder with Flat End
- Shank Type: FG (Friction Grip)
- Grit Type: Fine diamond grit
- Compatibility: Airotors
- Sterilization: Autoclavable
Packaging
- Pack of 5
Directions for Use
-
Sterilization:
- Ensure the bur is sterilized before use to maintain hygiene and prevent cross-contamination. Use autoclaving or other recommended sterilization methods.
-
Speed Regulation:
- Operate the bur at the appropriate rotational speed as per manufacturer guidelines to achieve optimal cutting efficiency and precision.
-
Application:
- For cavity preparation, gently guide the bur to remove decayed material and shape the cavity.
- Use it to form inner walls with precision, ensuring smooth surfaces for restorative materials.
- Create retention grooves for enhanced stability of restorative materials, maintaining steady control to avoid excess removal of healthy tooth structure.
-
Cooling:
- Use adequate water spray during operation to prevent overheating, which could damage both the bur and the tooth.
-
Inspection:
- After the procedure, inspect the bur for wear or damage and replace if necessary for consistent performance.
-
Storage:
- Clean, dry, and store the bur in a designated, sterile environment to maintain its longevity and cutting efficiency.
Warranty & Service
- Warranty is not applicable for this product
